Cylinder bore (mm) 缸径(mm) |
32 | 40 | 50 | 63 | 80 | 100 | ||
|
Action mode 动作方式 |
Single rod double action 单杆双作用 |
|||||||
|
Using fluid 使用流体 |
Air 空气 |
|||||||
|
Ensure pressure resistance 保证耐压力 |
1.5MPa | |||||||
|
Maximum operating pressure 最高使用压力 |
1.0MPa | |||||||
|
Minimum operating pressure 最低使用压力 |
0.05MPa | |||||||
|
Environmental temperature and fluid temperature used 环境温度及使用流体温度 |
Magnetic rings for non-magnetic switches-10℃~70℃(Not frozen) 无磁性开关用磁环：-10℃~70℃(无冻结) Magnetic rings for magnetic switches-10℃~60℃(Not frozen) 带磁性开关用磁环：-10℃~60℃(未冻结) |
|||||||
|
Oil supply 给油 |
No need (not supply oil) 无需(不给油) |
|||||||
|
Using piston speed 使用活塞速度 |
50~1000 mm/s | |||||||
|
Buffer 缓冲 |
Cushion buffering 垫缓冲 |
|||||||
|
Allowable kinetic energy J 允许动能J |
0.29 | 0.52 | 0.91 | 1.54 | 2.71 | 4.54 | ||
|
Stroke length tolerance 行程长度允差 |
+1.0 0 |
mm注) | ||||||
