Cylinder bore (mm) 缸径(mm) |
12 | 16 | 20 | 32 | 40 | 50 |
|
Action mode 动作方式 |
Double action, double action (with built-in spring), single action (with spring pressed out) 双作用、双作用(内置弹簧)、单作用(弹簧压出) |
|||||
|
Rod end shape 杆端形状 |
Cylindrical type, flat cylindrical type, roller type 圆柱型、扁柱型、滚轮型 |
Cylindrical type, flat cylindrical type, roller type, lever roller type(with built-in buffer) 圆柱型、扁柱型、滚轮型、杠杆式滚轮型(内置缓冲器) |
||||
|
Using fluid 使用流体 |
Air 空气 |
|||||
|
Minimum operating pressure 最高使用压力 |
1.0MPa | |||||
|
Environment and fluid temperature 环境和流体温度 |
Non magnetic switch: -10~+70℃, Magnetic switch -10~+60℃(but not frozen) 无磁性开关：-10~+70℃(但未冻结) 带磁性开关：-10~+60℃(但未冻结) |
|||||
|
Buffer 缓冲 |
Rubber buffer at both ends 两端橡胶缓冲 |
|||||
|
Stroke length tolerance (mm) 行程长度公差(mm) |
+1.4 0 |
|||||
|
Oil supply 给油 |
No need(Use turbine No.1 oil ISO VG32 for oil supplying) 不需要(给油时，用透平1号油ISO VG32) |
|||||
|
Installation form 安装形式 |
Through-hole, Screw holes at both ends 通孔、两端螺孔 |
|||||
|
Connecting pipe bore 接管口径 |
M5x0.8 | Rc1/8 | ||||
|
Quick change connector connection 快换接头连接 |
- | φ6/φ4 | φ8/φ6 | |||
