Cylinder bore (mm) 缸径(mm) |
φ6 | φ10 | |
|
Using fluid 使用流体 |
Air 空气 |
||
|
Action type 动作型式 |
Double action 双作用 |
||
|
Maximum operating pressure 最高使用压力 |
0.7MPa | ||
|
Minimum operating pressure 最低使用压力 |
0.15MPa | ||
|
Environment and fluid temperature 环境和流体温度 |
-10℃~60℃(But not frozen) -10℃~60℃(但未冻结) |
||
|
Oil supply 给油 |
No need 不需要 |
||
|
Piston speed 活塞速度 |
50~500mm/s | ||
|
Stroke length tolerance 行程长度公差 |
0~+1.0mm | ||
|
Buffer 缓冲 |
Rubber buffer at both ends 两端橡胶缓冲 |
||
|
Thread tolerance 螺纹公差 |
JIS2 level JIS2级 |
||
|
Connecting pipe bore 接管口径 |
M3×0.5 | ||
|
Diameter of guide rod 导杆直径 |
φ5 | φ6 | |
|
Allowable kinetic energy J 允许动能(J) |
0.012 | 0.035 | |
