产品
product
|
Model/item 型号项目 |
Connecting pipe 接管 |
Size of actuator (mm) 执行器大小(mm) |
Flow rate caliber 流通孔径 (mm) |
Kv value Kv 值 |
Minimum control pressure (bar) 最小控制压力(bar) |
Maximum operating pressure difference (bar) 最大操作压差(bar) |
Weight (kg) 重量 (kg) |
|
|
Z2JS150 Z2JW150 |
-10 | G3/8 | 40 | 15 | 4.4 | 4.8 | 13 | 0.8 |
| -15 | G1/2 | 0.7 | ||||||
| -10 | G3/8 | 50 | 4.8 | 4.3 | 16 | 0.8 | ||
| -15 | G1/2 | 0.7 | ||||||
|
Z2JS200 Z2JW200 |
-20 | G3/4 | 40 | 20 | 7.9 | 4.8 | 6.5 | 0.9 |
| 50 | 8 | 4.3 | 11 | 0.95 | ||||
| 63 | 10 | 4.2 | 16 | 1.6 | ||||
|
Z2JS250 Z2JW250 |
-25 | G1 | 63 | 25 | 19 | 4.2 | 11 | 1.9 |
| 80 | 20 | 5.0 | 16 | 2.5 | ||||
|
Z2JS320 Z2JW320 |
-32 | G1 1/4 | 63 | 32 | 27 | 4.2 | 6 | 2.5 |
| 80 | 28 | 5.0 | 15 | 3.0 | ||||
| Z2JSK150 Z2JWK150 | -10 | G3/8 | 40 | 15 | 4.4 |
Please refer to the control pressure relationship curve of normally open fluid pressure for details 详见常开型 流体压力——控制压力关系曲线图 |
16 | 0.8 |
| -15 | G1/2 | 0.7 | ||||||
| -10 | G3/8 | 50 | 4.8 | 16 | 0.8 | |||
| -15 | G1/2 | 0.7 | ||||||
|
Z2JSK200 Z2JWK200 |
-20 | G3/4 | 40 | 20 | 7.9 | 16 | 0.9 | |
| 50 | 8 | 16 | 0.9 | |||||
|
Z2JSK250 Z2JWK250 |
-25 | G1 | 50 | 25 | 14.5 | 16 | 1.2 | |
| 63 | 19 | 16 | 1.6 | |||||
|
Z2JSK320 Z2JWK320 |
-32 | G1 1/4 | 63 | 32 | 27 | 16 | 2.2 | |
| 80 | 28 | 16 | 2.4 | |||||
|
Z2JSY150 Z2JWY150 |
-10 | G3/8 | 40 | 15 | 4.4 |
Please refer to the control pressure relationship curve of normally closed fluid pressure for details 详见常闭型 流体压力——控制压力关系曲线图 |
16 | 0.8 |
| -15 | G1/2 | 0.7 | ||||||
| -10 | G3/8 | 50 | 4.8 | 16 | 0.8 | |||
| -15 | G1/2 | 0.7 | ||||||
|
Z2JSY200 Z2JWY200 |
-20 | G3/4 | 40 | 20 | 7.9 | 16 | 0.9 | |
| 50 | 8 | 16 | 0.9 | |||||
|
Z2JSY250 Z2JWY250 |
-25 | G1 | 50 | 25 | 14.5 | 16 | 1.3 | |
| 63 | 19 | 16 | 1.7 | |||||
|
Z2JSY320 Z2JWY320 |
-32 | G1 1/4 | 63 | 32 | 27 | 16 | 2.3 | |
