Cylinder bore (mm) 缸径(mm) |
25 | 32 | 40 | 50 | 63 |
|
Using fluid 使用流体 |
Air空气 | ||||
|
Action mode 动作方式 |
Double action 双作用 Single action: spring pressed back/spring press out 单作用：弹簧压回/弹簧压出 |
||||
|
Maximum operating pressure 最高使用压力 |
0.7MPa | ||||
|
Minimum operating pressure 最低使用压力 |
Double action: 0.05MPa Single action：0.18MPa 双作用：0.05MPa 单作用：0.18MPa |
||||
|
Environment and fluid temperature 环境和流体温度 |
-10～60℃ | ||||
|
Piston speed 活塞速度 |
50～500mm/s | ||||
|
Buffer 缓冲 |
Rubber buffer at both ends 两端橡胶缓冲 |
||||
|
Stroke tolerance 行程公差 |
+1.4 0 |
||||
|
*Oil supply *给油 |
No need 不需要 |
||||
|
Non-rotating precision of rod 杆不回转精度 |
±1° | ±0.8° | ±0.5° | ||
|
Connecting pipe bore Rc 接管口径 Rc |
M5×0.8 | 1/8 | 1/4 | ||
