Size 大小 |
05 | 1 | ||||
|
Basic type 基本型 |
External limiters 外部限位器 |
Basic type 基本型 |
||||
|
Using fluid 使用流体 |
Air (not supply oil) 空气(不给油) |
|||||
|
Operating pressure range 使用压力范围 |
0.15～0.7MPa | |||||
|
Environment and fluid temperature 环境及流体温度 |
0～60℃(not frozen) 0～60℃(未冻结) |
|||||
|
Swinging angle 摆动角度 |
90° |
+8 0 |
90°、180° | 90° |
+8 0 |
|
| 100° |
+10 0 |
100° |
+10 0 |
|||
| 180° |
+8 0 |
180° |
+8 0 |
|||
| 190° |
+10 0 |
190° |
+10 0 |
|||
|
Angle adjustable range 角度可调范围 |
- |
±5° for each swinging end 各摆动端±5° |
- | |||
|
Cylinder bore 缸径 |
Φ6 | Φ8 | ||||
|
Piping bore 配管口径 |
M3×0.5 | |||||
| Allowable kinetic energy允许动能(mJ) | 0.25 | 1.0 | 0.4 | |||
|
Swinging adjustable range 摆动可调范围 |
0.1～0.5s/90° | |||||
