Cylinder bore (mm) 缸径(mm) |
30 | 50 | 63 | 80 | 100 | |
|
Using fluid 使用流体 |
Air 空气 |
|||||
|
Action mode 动作方式 |
Double action 双作用 |
|||||
|
Maximum operating pressure 最高使用压力 |
1MPa | |||||
|
Minimum operating pressure 最低使用压力 |
0.1MPa | |||||
|
Environment and fluid temperature 环境和流体温度 |
0～60℃(but not frozen) 0～60℃(但未冻结) |
|||||
|
Backlash 齿隙 |
Within 1° (Φ30 Due to the built-in limiter, there is no backlash during pressurization) 1°以内(Φ30因内置限位器，加压时无齿隙) |
|||||
|
Tolerance of swing Angle 摆动角度允差 |
+4° 0 |
|||||
|
*Oil supply *给油 |
No need 不需要 |
|||||
|
Output torque 输出力矩(N·m) |
1.9 | 9.3 | 17 | 32 | 74 | |
|
Allowable kinetic energy 允许动能J |
No air buffering无气缓冲 | 0.01 | 0.05 | 0.12 | 0.16 | 0.54 |
| Air buffering气缓冲 | - | 0.98 | 1.5 | 2.0 | 2.9 | |
|
Swinging time range (seconds/90°) 摆动时间范围(秒/90°) |
0.2～1 | 0.2～2 | 0.2～3 | 0.2～4 | 0.2～5 | |
|
Connecting pipe bore Rc 接管口径 Rc |
M5×0.8 | 1/8 | 1/8 | 1/4 | 3/8 | |
