Cylinder bore(mm) 缸径(mm) |
20 | 25 | 32 | 40 |
|
Using fluid 使用流体 |
Air (without oil supply) 空气(不给油*) |
|||
|
Action mode 动作方式 |
Double action 双作用 |
|||
|
Maximum operating pressure 最高使用压力 |
1.0MPa | |||
|
Minimum operating pressure MPa 最低使用压力 |
0.05MPa | |||
|
Environment and fluid temperature 环境和流体温度 |
Non magnetic switch: -10°C~70°C, Magnetic switch: -10°C~60 °C 无磁性开关：-10℃~70℃，带磁性开关：-10℃~60℃ |
|||
|
Piston speed 活塞速度 |
50~750 mm/s | |||
|
Buffer 缓冲 |
Rubber buffer/ Air buffering 橡胶缓冲/气缓冲 |
|||
|
Stroke tolerance range mm 行程公差mm |
+1.4 0 |
|||
|
*Oil supply *给油 |
No need 不需要 |
|||
|
Connecting pipe bore 接管口径(Rc) |
1/8 | 1/8 | 1/8 | 1/4 |
