Product Description
|
Cylinder bore (mm) 缸径(mm) |
12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | |||
|
Using fluid 使用流体 |
Air 空气 |
||||||||||||
|
Action mode 动作方式 |
Double action 双作用 |
||||||||||||
|
Maximum operating pressure 最高使用压力(MPa) |
1.0 | ||||||||||||
|
Minimum operating pressure 最低使用压力(MPa) |
0.12 | 0.1 | |||||||||||
|
Environment and fluid temperature℃ 环境和流体温度℃ |
-10～+60(But not frozen) -10～+60(但未冻结) |
||||||||||||
|
Piston speed mm/s 活塞速度mm/s |
50~500 | 50~400 | |||||||||||
|
Buffer 缓冲 |
Rubber buffering at both sides 两侧橡胶缓冲 |
||||||||||||
|
Stroke length tolerance 行程长度公差 |
+0.15 0 |
mm | |||||||||||
|
Oil supply *给油 |
No need 不需要 |
||||||||||||
|
Bearing 轴承 |
Sliding bearing / ball bearing 滑动轴承/球轴承 |
||||||||||||
|
Precision of piston rod non-rotating 活塞杆不回转精度 |
Sliding bearing 滑动轴承 |
±0.08° | ±0.07° | ±0.06° | ±0.05° | ±0.04° | |||||||
|
Ball bearing 球轴承 |
±0.10° | ±0.09° | ±0.08° | ±0.06° | ±0.05° | ||||||||
|
Connecting pipe bore 接管口径 |
M5×0.8 | 1/8 | 1/4 | 3/8 | |||||||||
