Product Description
|
Cylinder bore (mm) 缸径(mm) |
20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | |||||
|
Using fluid 使用流体 |
Air 空气 |
||||||||||||
|
Action mode 动作方式 |
Double action 双作用 |
||||||||||||
|
Maximum operating pressure 最高使用压力 |
1.0MPa | ||||||||||||
|
Minimum operating pressure 最低使用压力 |
0.15MPa (When there is no load horizontally) 0.15MPa(水平无负载时) |
||||||||||||
|
Environment and fluid temperature 环境和流体温度 |
-10~60°℃(Not frozen) -10~60°℃(未冻结) |
||||||||||||
|
Piston speed 活塞速度 |
50~1000 mm/s | 50~700 mm/s | |||||||||||
|
Buffer 缓冲 |
Cylinder rubber buffer/guide rod with built-in hydraulic buffer (2 PCS) 气缸橡胶缓冲/导杆内置液压缓冲器(2个) |
||||||||||||
|
Stroke tolerance(mm) 行程公差(mm) |
-1000 |
+1.9 +0.2 |
,1001-1300 |
+2.3 +0.2 |
|||||||||
|
Stroke djustable range (one side) (mm) 行程可调范围(单侧)(mm) |
0~-10 | 0~-15 | |||||||||||
|
Maximum absorbed energy 最大吸收能量(J) |
5.88 | 19.6 | 58.8 | 147 | |||||||||
|
*Oil supply *给油 |
No need 不需要 |
||||||||||||
|
Bearing 轴承 |
Sliding bearing / ball bearing 滑动轴承/球轴承 |
||||||||||||
|
*Precision of piston rod non-rotating *活塞杆不回转精度 |
Sliding bearing 滑动轴承 |
±0.07° | ±0.06° | ±0.05° | ±0.04° | ±0.03° | |||||||
|
Ball bearing 球轴承 |
±0.06° | ±0.05° | ±0.04° | ±0.03° | ±0.02° | ||||||||
|
Connecting pipe bore Rc 接管口径Rc |
1/8 | 1/4 | 3/8 | 1/2 | |||||||||
