Cylinder bore (mm) 缸径(mm) |
6 | 10 | 16 | 20 | 25 | 32 | ||
|
Using fluid 使用流体 |
Air 空气 |
|||||||
|
Action mode 动作方式 |
Double action双作用 Single action: Spring pressed back/spring pressed out 单作用：弹簧压回/弹簧压出 |
|||||||
|
Maximum operating pressure 最高使用压力 |
0.7MPa | |||||||
|
Minimum operating pressure 最低使用压力MPa |
Double action 双作用 |
Single rod单杆 | 0.12 | 0.06 | 0.05 | |||
|
Double rod, non-rotating air buffering 双杆、杆不回转气缓冲 |
0.15 | 0.10 | 0.08 | |||||
|
Rod non-rotating(double rod) 杆不回转双杆 |
0.18 | 0.13 | 0.11 | |||||
|
Single action 单作用 |
Standard标准 | 0.20 | 0.15 | 0.13 | ||||
| Rod non-rotating杆不回转 | 0.23 | 0.18 | 0.16 | |||||
|
Environment and fluid temperature 环境和流体温度 |
Magnetic switch：-10~60℃, Non magnetic switch：-10~70℃ 带磁性开关：-10~60℃,无磁性开关：-10~70℃ |
|||||||
|
Buffer 缓冲 |
Rubber buffer at both ends 两端橡胶缓冲 |
|||||||
|
Using piston speed 使用活塞速度 |
50~500mm/s | |||||||
|
Stroke tolerance(mm) 行程公差(mm) |
+1.0 0 |
|||||||
|
Oil supply *给油 |
No need 不需要 |
|||||||
|
Installation form 安装形式 |
Free (multi sided installation) 自由(多面安装) |
|||||||
|
Precision of piston rod non-rotating 活塞杆不回转精度 |
±0.8° | ±0.5° | ||||||
|
Connecting pipe bore 接管口径 |
M5X0.8 | 1/8 | ||||||
