| Size尺寸 | 1 | 2 | 3 | 7 |
|
Using fluid 使用流体 |
Air (without oil supply) 空气(不给油) |
|||
|
Maximum operating pressure 最高使用压力 |
0.7 | |||
|
Minimum operating pressure 最低使用压力 |
01 | |||
|
Environmental temperature and fluid temperature used 环境温度及使用流体温度 |
0～60℃(but not frozen) 0～60℃(但未冻结) |
|||
|
Buffer 缓冲 |
None无 |
Cushion buffering 垫缓冲 |
||
|
Angle adjustment range 角度调整范围 |
0～190° | |||
|
Maximum swing angle 最大摆动角度 |
190° | |||
|
Cylinder bore 气缸内径 |
Φ6 | Φ8 | Φ10 | Φ12 |
|
Through-hole side 通口尺寸 |
3×0.5 | 5×0.8 | ||
