产品
product
| Model型号 | ZMSUB1 | ZMSUB3 | ZMSUB7 | ZMSUB20 | ||||||
|
Blade form 叶片形式 |
Single blade 单叶片 |
|||||||||
|
Swinging angle 摆动角度 |
90°±10° | 180°±10° | 90°±10° | 180°±10° | 90°±10° | 180°±10° | 90°±10° | 180°±10° | ||
|
Using fluid 使用流体 |
Air (without oil supply) 空气(不给油) |
|||||||||
|
Environment and fluid temperature 环境及流体温度 |
5~60℃ | |||||||||
|
Operating pressure range 使用压力范围(MPa) |
0.2~0.7 | 0.15~0.7 | 0.15~1.0 | |||||||
|
Adjustable range of swing time (0.5MPa) 摆动时间可调范围(0.5MPa) |
0.07~0.3s/90° | |||||||||
| Bearing轴承 | Bearing轴承 | |||||||||
|
Connecting pipe port 接管口径 |
Body side 本体侧面 |
M3×0.5 | M5×0.8 | |||||||
|
Swinging accuracy 摆动精度 |
Within 0.03mm 0.03mm以内 |
|||||||||
|
Allowable axial load 允许轴负载 |
Radial径向(N) | 20 | 40 | 50 | 60 | |||||
| Axial轴向(N) | 15 | 30 | 60 | 80 | ||||||
|
Torque(N-m) 力矩(N-m) |
0.3 | 0.7 | 0.9 | 2.9 | ||||||
