Cylinder bore(mm) 缸径(mm) |
10 | 16 | 20 | 25 | |||
|
Using fluid 使用流体 |
Air 空气 |
||||||
|
Action mode of air claws 气爪部动作方式 |
Single action·Double action 单作用·双作用 |
||||||
|
Operating pressure range 使用压力范围 (MPa) |
Rotating part 回转部 |
0.25~0.7 | 0.25~1.0 | ||||
|
Air claw part 气爪部 |
Double action 双作用 |
0.25~0.7 | 0.1~0.7 | ||||
|
Single action 单作用 |
0.35~0.7 | 0.25~0.7 | |||||
|
Swinging angle 摆动角度 |
90°±10°,180°±10 | ||||||
|
Finger opening and closing repetition accuracy of air claw part 气爪部手指开闭重复精度 |
±0.01mm | ||||||
|
Maximum action frequency of air claw part 气爪部最高动作频度 |
180 c.p.m | ||||||
|
Environment and fluid temperature 环境及流体温度 |
5~60℃, (but not frozen) 5~60℃，(但未冻结) |
||||||
|
Swing adjustable time 摆动可调时间 |
0.07~0.3s/90°(When 0.5MPa) 0.07~0.3s/90°(0.5MPa时) |
||||||
|
Allowable kinetic energy 允许动能(J) |
0.0046 | 0.014 | 0.034 | 0.074 | |||
|
Air claw opening and closing stroke (mm) 气爪开闭行程(mm) |
4 | 6 | 10 | 14 | |||
