Inner diameter (mm) 内径(mm) |
6 | 8 | 12 | 16 | 20 | 25 | ||||
|
Action type 动作型式 |
Double action type 复动型 |
|||||||||
|
Working medium 工作介质 |
Air (passing through over 40μm filter) 空气(经40μm以上滤网过滤) |
|||||||||
|
Operating pressure range 使用压力范围 |
0.15~0.7MPa(22~100psi)(1.5~7.0bar) | |||||||||
|
Ensure pressure resistance 保证耐压力 |
1.2MPa(175psi)(12.0bar) | |||||||||
|
Working temperature °C 工作温度℃ |
-20~70 | |||||||||
|
Operating speed range 使用速度范围mm/s |
50~500 | |||||||||
|
Stroke tolerance range 行程公差范围mm |
Stroke≤100 |
+1.0 0 |
Stroke>100 |
+1.5 0 |
||||||
| 行程≤100 |
+1.0 0 |
行程>100 |
+1.5 0 |
|||||||
|
Buffering type 缓冲型式 |
Fixed buffering at both ends, oil buffering 两端固定缓冲、油压缓冲器缓冲 |
|
||||||||
|
Sensor 所配传感器 |
CMSH、DMSH(S) | |||||||||
|
Connecting pipe bore 接管口径① |
M5×0.8 | PT1/8 | ||||||||
