Inner diameter (mm) 内径(mm) |
6 | 10 | 16 | 20 | ||
|
Guide rail width 导轨宽度mm |
5 | 7 | 9 | 12 | ||
|
Action type 动作型式 |
Double action type 复动型 |
|||||
|
Working medium 工作介质 |
Air (passing through over 40μm filter) 空气(经40μm以上滤网过滤) |
|||||
|
Operating pressure range 使用压力范围 |
0.15~0.7MPa(22~100psi)(1.5~7.0bar) | |||||
|
Ensure pressure resistance 保证耐压力 |
1.2MPa(175psi)(12.0bar) | |||||
|
Working temperature °C 工作温度℃ |
-20~70 | |||||
|
Operating speed range 使用速度范围mm/s |
50~500 | |||||
|
Permissible movement energy J 容许运动能量J |
0.08 | 0.025 | 0.05 | 0.1 | ||
|
Stroke tolerance range 行程公差范围 |
Stroke≤100 |
+1.0 0 |
||||
| 行程≤100 |
+1.0 0 |
|||||
|
Buffering type 缓冲型式 |
Fixed buffering at both ends 两端固定缓冲 |
|||||
|
Sensor 所配传感器 |
CMSH、DMSH(S) | |||||
|
Connecting pipe bore 接管口径 |
M5×0.8 | |||||
